NEW CARDING SET siutable for high quality cashmere, working with: 1800mm, 2000mm or 2500mm, all in single block steel composed as follows:

全新梳毛機，適合生產高質量粗紡羊絨紗，幅寬: 1800mm, 2000mm 或2500mm，所有主結構為整體鋼制結構，組成如下：

-   N.1 AUTOMATIC HOPPER FEEDER

N.1 自動喂毛斗

-   N.1 BREAST

N.1胸錫林

-   N.1 FIRST CARD

N.1第一梳理組

-   N.1 FIBER TRANSPORTER OF 45° WITH UNDERGROUND PASSAGE

N.1下過橋

-   N.1 INLET BENCH

N.1喂入簾

-   N.1 SECOND CARD

N.1第二梳理組

-   N.1 PERALTA

N.1壓草輥

-   N.1 FIBER TRANSPORTER OF 45° WITH UNDERGROUND PASSAGE

N.1下過橋

-   N.1 INLET BENCH

N.1喂入簾

-   N.1 THIRD CARD

N.1第三梳理組

-   N.1 CONVEYOR BELT FOR VEIL to the fourth finishing card

到第四梳理組的毛網輸送簾

-   N.1 FOURTH CARD (FINISHING CARD)

N.1第四梳理組（末梳）

-   N.1 DIVIDING CONDENSER WITH SINGLE BELT

N.1單根分割車頭

-   N.1 FLOATING BENCH

N.1搓皮板車架

-   N.1 SUPERCHAMMLER FOR MATERIAL RECOVERY

N.1往復卷繞車架

AUTOMATIC HOPPER FEEDER composed as follows:

自動喂毛斗組成如下

-   Steel carrying flanks

鋼制機架

-   N.1 scale with pneumatic opening, electronic loading bins

1臺稱量裝置帶氣動開斗，電子裝料箱

-   N.1 counter-scale with pneumatic functioning for stopping the eventual falling material once the weighing is carried out

一旦稱重完成數字稱帶氣動功能控制浮游纖維

-   N.1 electronic terminal composed by one multiprocessor system for the weight management

電子終端由多處理系統組成用于管理稱重

-   N.4 motoreducers for conveyor belts control, everything controlled by general electric control panel by means of n.4 inverters

4個減速電機用傳送簾子控制，所有過程由4個變頻器驅動

-   N.1 switchboard equipped with PLC for the management of the various working phases of the machine

配電盤裝備PLC控制管理各工作周期

-   Everything completed with conveyor belts in PVC fitted on polyzene guides

包括PVC傳送簾的所有部件都裝在Polyzene導輥上

-   Dragging of the main conveyor belt by means of rolls ? 200mm

直徑193毫米輥傳動主簾

-   N.1 feeding bench to the breast cylinder with inclined belt for conveying  material to inlet cylinders

胸錫林喂入簾上有斜壓簾

-   Machine completely fitted on bearings

全軸承化

BREAST equipped with inlet group composed by

胸錫林帶喂入組件組成如下:

-   Structure  in steel with outside foot support

鋼構件帶外支撐腳

-   N.2 inlet cylinders ? 92 mm with rigid clothing and N. 1 Discharge Cylinder ? 80

2個直徑92毫米喂入輥，包金屬針布，1個直徑80毫米剝取輥

-   N.1 inlet cylinder ? 320 mm with rigid clothing

1個直徑320毫米開毛輥，金屬針布

-   N.1 Breast  drum ? 1650 mm

1個胸錫林直徑1650毫米

-   N.7 couples of workers ? 270mm and Striper Cylinder ? 105mm

7對直徑270毫米工作輥和直徑105毫米剝毛輥

-   N.1 couple of worker ? 350mm and Striper Cylinder ? 150mm

1對直徑350毫米工作輥和直徑150毫米剝毛輥

-   Pneumatic Cup rising system on upper  cover of Card

胸錫林上罩氣動提升系統

-   N.1 Transfer Cylinder for material to First Card ? 1000mm

1個轉移輥直徑約1000毫米

CARDS composed by

各道梳理機組成:

-   Structure out of steel with outside foot support

鋼構件帶外支撐腳

-   N.1 Card drum ? 1650 mm

錫林直徑1650毫米

-   N.7 couples of workers ? 260mm and Striper Cylinder ? 92mm

7對直徑260毫米工作輥和直徑92毫米剝毛輥

-   N.1 fly-wheel ? 350 mm

風輪直徑350毫米

-   N.1 lower Fly wheel ? 112 mm

下擋風直徑112毫米

-   Pneumatic Cup rising system on upper part of Card

錫林上罩氣動提升系統

-   N.1 Doffer ? 1280 mm

道夫直徑1280毫米

-   Doffing comb

斬刀箱

CONDENSER WITH single belt

單根分割車頭:

      - Frame out of steel

        鋼制墻板

      - Machine completely fitted on bearings

        全部裝備滾柱軸承

      - N. 2 web tensioning cylinders ? 120 mm out of anodized aluminum

        2根毛網張力輥直徑120毫米，陽極電鍍鋁制

      - N. 2 Grooved splitting cylinders ? 120 mm with steel-ringed aluminum parts

        2根有槽分割輥直徑120毫米，鋼環鋁部件

      - N. 2 grooved preparatory guide cylinders ? 104mm

        2根有槽導向輥直徑104毫米

      - N. 6 Steel preparatory-holders cylinders ? 92mm

        6根預握持輥

      - Variator for web tensioning between rubbing aprons and preparatory

        在搓皮板和預固定輥之間毛網張力變速器

FLOATING BENCH composed by

搓皮板架組成如下:

-   Carrying structure in steel

鋼制支撐構件

-   Tempered and rectified shafts to cylinders floating bench sliding on self-lubricating bushings

回火調校軸到搓皮板架輥滑動在自潤滑軸承中

-   Machine completely assembled on ball bearings

機器完全安裝在滾珠軸承上

-   Big floating bench with blank from sleeves 1080 mm

大搓皮板框架可容納外周長1080毫米的搓皮板

-   N.12 support cylinder for rubbing aprons

12根搓皮板支撐軸

-   Shaft column ? 50mm with eccentrics on clamping

立軸直徑50毫米帶偏心筘位

-   Equalizer in monoblock steel with central temperate pins on roller bearings

整塊鋼制均衡器帶中心銷，裝有滾柱軸承

-   Bearings with double series on each head of cylinders for moving rubbing aprons

移動搓皮板的軸頭裝有雙列軸承

GENERAL TECHNICAL FEATURES OF THE MACHINE

機器總的技術特點：

-   Variator for the right veil tightening present in all passage phases from one working cycle to the following one

所有梳理組的工作周期由變速器調整正確的毛網張力

-   Speed Variator for the control of one cam column of the floating benches

變速器控制搓皮板的凸輪立軸

-   Speed Variator for material outlets of cards

變速器控制梳理機的毛網輸出

-   Speed Variator for doffing combs

斬刀變速器

N.1 COMPLETE LATERAL PROTECTION GUARD on wheels with transparent polycarbonate

整套帶輪子聚碳酸酯透明窗側防護裝置

N.1 ELECTRIC CONTROL PANEL for Carding Set with  following features:

控制整臺機器的電控柜具有以下特點：

-         Management of N.3 AC motors driven by inverters

由變頻器控制管理3臺交流電機

-         False threads suction control

邊條回收吸風控制

-         Line for Hopper Feeder feeding

毛斗喂入在線控制

-         Control of all various work steps of the machine and security by means of PLC and operator interface panel

由PLC和操作交互界面控制柜控制機器的各個工作步驟和安全

-         Machine diagnostics

機器診斷

-         Ventilation for cooling

通風裝置用于冷卻
