拉鏈卷帶機、拉鏈卷帶機、卷帶機、拉鏈卷繞機、拉鏈繞帶機
發布時間：2017-05-21
拉鏈卷帶機(大盤頭) TS-ZB
Zipper winding machine（Big bobbin）
技術特點 Features
1. 操作方便，每人可操作2~3臺，提高工作效率。
Easy to operate, each person can operate 2~3 , improve work efficiency.
2. 采用優質剎車馬達和調速變頻器，卷帶速度可任意調節。
The use of brake motor and speed control frequency converter, Winding speed can be adjusted.
3. 排線器運行距離和速度可任意調整，以適配不同型號寬度的拉鏈，布帶，使卷帶效果更佳。
The traverse unit running distance and speed can be adjusted to fit the different models of the width of the zipper, cloth, so that the tape effect better.
4. 機器實現高智能化，無帶，卡帶，斷帶，接頭等自動感應并立即停機。采用高精度計數器，計數定量準確。
The machine to achieve high intelligence, no zipper or knot will automatically sense and immediately stop. Using high-precision counter, count quantitative and accurate.
5. 采用氣動裝卸盤管的方式，更加安全，省力，高效。
The use of pneumatic handling bobbin way, more secure, effort and efficiency.
6. 大盤頭卷帶機，弧度大，接頭少，易燙平，染色變形小，適用于大規格批量生產，30KG卷帶約需15分鐘。
Large bobbin winding machine has high curvature, joint less, easy ironing,little color change, suitable for large-scale mass production, winding 30KG about 15 minutes.
7. 可選配分段恒速自動卷帶系統：可視化觸屏和自動操控系統，使得操作更為簡便；整個卷帶過程分為三段不同的速度并可以單獨設定，用此型卷帶機卷出來的拉鏈，能很好的控制管底、管中、管面織帶/拉鏈的色差和質量；在實際使用過程中，得到所有客戶的一致認可和好評。
Can be equipped with constant tension winding system, and the visual touch screen control system, which makes the operation more simple;The speed of the winding with the increase of the diameter of the coil, is gradually slowing down,achieve constant speed constant tension effect, zipper and tightness consistent, the same tension, improve dyeing effect will reduce the zipper dyeing color and flower belt, reduce zipper in the dyeing process of deformation.
