重磅帆布劍桿織機是專為厚重高密帆布生產而設計的，鄭州豫達紡機是首家設計、生產和

出口此機型的廠家。

Heavy canvas rapier loom is especially designed for the thick-heavy and high-

density canvas.

Zhengzhou yuda textile machinery is the first factory to design, produce and

export this kind

 of heavy-canvas rapier loom.

主要技術參數 Main technical information

1 、帆布組織 canvas structure:16s/5X16s/3-38X36

2、筘幅 reed width:180cm, 200cm, 230cm

3 、織機車速 loom speed:170-200rpm(180cm,200cm)

                       165rpm(230cm)

4、經軸盤片直徑Diameter of warp beam flanges:ф600mm

5 、最大卷布直徑Max-rolling-up diameter:ф380mm  Ф1500mm

6、綜框頁數heald frame:4pcs

7 、電機速度和功率Motor speed and power:945rpm and 2.2kw
